Description
Hot Water Ignitors – 120 VAC
Beckett’s PowerLight® 120 VAC fuel oil igniters offer improved performance and longer life. This igniter is easy to install and is designed as a universal replacement for Beckett and other manufacturer’s igniters. The PowerLight igniter is available either with or without a factory-installed baseplate.
Technical Specifications
Input Voltage: 120 VAC, 50-60 Hz, 35 VA
Output Voltage: 6kV RMS, 20kV peak
Output Current: 35 mA RMS
Secondary Mid-point Ground
Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
Storage Temperature: -40°F (-40°C) to 150°F (66°C)
Moisture: 5 to 95% Relative Humidity
Available in 3 configurations
Beckett A, AF with Base (51771U)
Beckett S with Base (51824U)
Ignitor only (51838U)
