Description
Hot Water Ignitors – 12 VDC
Beckett Powerlight® Igniters are 12-volt DC powered ignitors for your hot water system. Designed as a universal replacement for Beckett Oil Burners this ignitor can be adapted to multiple base plates to accommodate Beckett ADC burners. It also serves as a universal replacement for other manufacturers’ igniters.
Technical Specifications
Input Voltage: 10.8 – 16 Vdc
Output Voltage: 20kV peak
Output Current: 25 mA RMS
Input Current: 2.5 A Maximum
Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
Storage Temperature: -40°F (-40°C) to 150°F (66°C)
Moisture: 5 to 95% Relative Humidity
Available in 3 configurations
Beckett ADC, AF with Cad Cell (5270001U)
Beckett SDC with Cad Cell (5270002U)
Ignitor only (5270005U)
